Function
The thermostatic regulator is intended to be installed in the return pipe of each re-circulation circuit, automatically maintaining the specified water temperature.
The regulator controls the flow rate in accordance with the inlet water temperature by means of a dedicated intemal themmostatic cartridge.
When the water temperature approaches the set value, the obturator progressively close and reduces the flow passage reducing the amount of water re-circulating.
The water supplied by the re-circulation pump is available to be distributed to other branches in the system, resulting in effective automatic thermal balancing.
Temperature gauge available.
Insulation shell available upon request

Connections –
Rp ½” but with 15mm conversation to compression supplied as
standard – for use with R250 (half hard) copper tube.
Rp ¾” but with 22mm conversation to compression supplied as
standard – for use with R250 (half hard) copper tube.
